Description
SPECIFICATIONS
| Models | DF6AL |
|---|---|
| Transom Height | 508 mm |
| Starting System | Manual |
| Weight | 25 kg |
| Engine Type | OHV |
| Piston Displacement | 138 cm3 |
| Bore x Stroke | 60.4 x 48 |
| Maximum Power | 4.4 kW {6HP} |
| Full Throttle Operating Range | 4.750 – 5.750 |
| Fuel Tank Capacity | Integral 1.0 |
| Ignition System | Digital CDI |
| Battery Charging | 12V 5A (op.) |
| Steering | Tiller |
| Trim Method (Positions) | Manual Trim and Tilt |
| Fuel/Oil Mixing Ratio | – |
| Gear Shift | F – N – R |
| Gear Ratio | 1.92 : 1 |
| Drive Protection | – |
| Fuel Delivery System | Carburetor |
| No of Cylinders | 1 |
| Choke | Manual |
| Oil Pan Capacity | 0.7 |
| Recommended Fuel | RON 91 |
| Exhaust | Above Prop Exhaust |
| Propeller Selection | 6 |
| Engine Mounting | Bushing Type |
FEATURES
| Over-Rev Limiter | – |
|---|---|
| Emergency Stop Switch | – |
| Start-in Gear Protection | – |
| Shallow Water Drive | Electric System |
| Loop Charge Fuel Induction | – |
| Dual Water Intakes | – |
| Through Prop Hub Exhaust | – |
| S.S. Water Pump Housing | – |
| Anti-Corrosion System | – |
