Description
SPECIFICATIONS
| Models | DT 30 L |
|---|---|
| Transom Height | 508 mm |
| Starting System | Manual |
| Weight | 57 kg |
| Engine Type | 2-Stroke |
| Piston Displacement | 499 cm3 |
| Bore x Stroke | 71 x 63 |
| Maximum Power | 22.1 kW {30HP} |
| Full Throttle Operating Range | 5.000-5.600 |
| Fuel Tank Capacity | 25 liter |
| Ignition System | Suzuki P.E.I. |
| Battery Charging | 12 V 80 W |
| Steering | Tiller |
| Trim Method (Positions) | Manual Trim and Tilt |
| Fuel/Oil Mixing Ratio | 50:1 |
| Gear Shift | F – N – R |
| Gear Ratio | 2.09 : 1 |
| Drive Protection | Rubber hub |
| Fuel Delivery System | Carburetor |
| No of Cylinders | 2 in-line |
| Choke | Manual |
| Recommended Fuel | RON 87 |
| Exhaust | Prop Hub |
| Propeller Selection | 10 |
| Engine Mounting | Bushing Type |
FEATURES
| Over-Rev Limiter | – |
|---|---|
| Emergency Stop Switch | Std. Equip |
| Start-in Gear Protection | Std. Equip |
| Shallow Water Drive | Std. Equip |
| Loop Charge Fuel Induction | Std. Equip |
| Dual Water Intakes | Std. Equip |
| Through Prop Hub Exhaust | Std. Equip |
| S.S. Water Pump Housing | Std. Equip |
| Anti-Corrosion System | Std. Equip |
