Description
Tohatsu 2-stroke benefits
- Excellent reliability with proven 2-stroke technology
- Simple in design
Easy operation and handling
- Loop charged induction for smooth operation and fuel economy
- CD ignition system for quicker starts
- Carrying handle
Fundamentals for user convenience and reliability
- High grade marine aluminum alloy that provides the ultimate protection against corrosion
- Zinc coating on internal water passages for superior corrosion resistance
- Shifting: Forward (F) – Neutral (N)
- Built-in fuel tank 1.4 liter
Protection
- Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
*B2 type only
SPECIFICATIONS
| Engine | Two Stroke 1 Cylinder |
|---|---|
| Output | 2.5 ps (1.8 kw) |
| Displacement | 74.6 cc (4.55 cu.in.) |
| Bore x Stroke | 55 x 43 mm (2.17 x 1.69 in) |
| Max. RPM Range | 4,200 – 5,300 |
| Starting | Manual |
| Control Type | Tiller Handle |
| Gear Shift | Forward – Neutral |
| Gear Ratio | A2 type 1.85:1 (13:24), B2 type 2.15:1 (13:28) |
| Propeller Selection Range | 4.5″ – 7″ |
| Transom Height | 15″, 20″ |
| Fuel | Unleaded Gasoline (87 Octane) |
| Oil Type | Genuine recommended 2stroke engine oil (TCW-3) |
| Fuel Tank | 1.4 L (0.37 US Gal.) Integral Tank |
| Weight* | 12.5 Kg (28 lbs.) |
| Start In Gear Protection | |
| Engine lubrication system | Premixed Fuel |
